Card Edge Header 2.54mm [.100″] Contact Centres, 13.72mm [.540″] Insulator Height

Name: Card Edge Header 2.54mm [.100"] Contact Centres, 13.72mm [.540"] Insulator Height
SKU: EBC25MMWD
Availability: InStock

£0.00

The EBC25MMWD is a male card edge header that can accommodate a 1.57mm thick PC board. This male connector is compatible with 10.95mm or 15.49mm insulator height card edges.

SKU: EBC25MMWD

Category: 2.54mm [.100"], All Products, Card Edge

Description

Description

The EBC25MMWD is a male card edge header that can accommodate a 1.57mm thick PC board. This male connector is compatible with 10.95mm or 15.49mm insulator height card edges.

Card Edge Header 2.54mm [.100″] Contact Centres, 13.72mm [.540″] Insulator Height

Description
