JCK10DKBS-1
JCK10DKBSdog
JCK10DKBSdrawing

Bi Level Card Edge Header 1.98mm [.050″] /3.96mm [.100″] Contact Centres

£0.00

The JCK10DKBS is a bi level female card edge header that can accommodate a 1.57mm thick PC board. The 1.98mm contact centre spacing can replace the 3.96mm contact centre part to double the number of contacts within the same area. This connector is backwards compatible with a daughter card side.

SKU: JCK10DKBS
Category: , , ,

Description

The JCK10DKBS is a bi level female card edge header that can accommodate a 1.57mm thick PC board. The 1.98mm contact centre spacing can replace the 3.96mm contact centre part to double the number of contacts within the same area. This connector is backwards compatible with a daughter card side.
