Belden 4505R Cable

General Description:

4K UHD Coax for 12G-SDI, 75 Ohm, RG-59, 20 AWG Solid SC, Foil + 95% TC Braid, PVC Jkt, CMR

Suitable Applications:

Ultra-High Definition Digital Video, 4K Single-link 12 Gb/s UHDTV, 4K D-Cinema, 8K Quad-link UHDTV, HD-SDI 1080p

Belden Cables are available in a range of colours to special order, with black as a standard colour.

We are able to offer cable assemblies or cable connectors to suit applications using this cable type. You can see more information about cable connectors on the links below and if you have a cable assembly you would like us to manufacture, please send more details to; sales@cambridgeelectronics.com

View the manufacturers datasheet

Cable Type	Cable Group	Operating Frequency	Impedance	Jacket Material / Size	Dielectric Material / Size	Centre Conductor Material / Size	Conductor Type	Shielding Outer Conductor
Belden 4505R	AB	DC-12GHz	75 ohms	PVC / 5.92mm	FHDPE / 3.68mm	Silver Plated Copper / 0.81mm	Solid	Tinned Copper Braid & Foil
